4X / 8X Chemi
GELSTAN CHEMILUMINESCENCE & FLUORESCENCE IMAGING
Applications:
- Fluorescence DNA/RNA
- Luminescence
- Bioluminescence
- Chemiluminescence
- Biofluorescence
- Colorimetry
- GFP
- Multiplexing of two or more images
- Chemiluminescence Western Blot
- Bacterial Colonies and host of imaging needs.
- Peltier and Two stage Peltier cooled CCD.
- Adjustable trays to suit Western blot / Small sample sizes.
- Exposure time settings, Binning (2×2, 4×4, 8×8), Signal accumulation through stacking, Time lapse exposure mode, Dark frame subtraction, etc.
- USB 3.1 interface for faster image capture.
- Time lapse software with up to 10 incremental images in a capture.
- Real time image viewing
- Exposure time ranges from 10 microseconds to 3600 seconds.
- Manual/Motorized/ Fixed Lens with f/0.95, 1.2 & 1.4 bright aperture.
- Dynamic Range: More than 4.8 orders of magnitude.
- 1D Freeware/GelAn software for Molecular weight and Intensity of band (Manual & Auto detection)
Every photon counts for Chemiluminescence detection. Our peltier-based CCD cooling ensures no photon is missed. Dark hood is fully sealed โ ABSOLUTE DARK HOOD.
Advantages:
- Fast, Simple, and clear imaging compared to film.
- Incident photon to converted electron (IPCE) ratio: ~85%
- 3X more efficient than photographic films
Model |
GELSTAN 4X Chemi-Solo |
GELSTAN 4X Chemi |
GELSTAN 8X Chemi |
Camera |
Scientific grade CCD |
Scientific grade CCD |
High-sensitive scientific grade CCD |
Image Resolutions |
1.4 MP / 3 MP / 4.0 MP |
11.4 MP / 18 MP |
11.4 MP / 18 MP |
Cooling |
Peltier |
Peltier |
Two-stage Peltier |
Temperature |
-30ยฐC |
-40ยฐC |
-45ยฐC |
Gray Scale/Depth |
655,536 / 16-bit AD |
655,536 / 16-bit AD |
655,536 / 16-bit AD |
Read Noise |
< 15 eโป |
< 15 eโป |
< 10 eโป |
Dark Current |
0.01 eโป/pixel/sec |
0.01 eโป/pixel/sec |
0.01 eโป/pixel/sec |
PC Interface |
Fast USB 3.0 |
Fast USB 3.0 |
Fast USB 3.0 |
Lens |
Pre-focused 16, 25mm |
Pre-focused 16, 25mm |
12โ75 mm |
Imaging Area |
16 ร 12 cm |
17 ร 13 cm |
20 ร 25 cm |
Pixel Size |
6.45 ร 6.45 ยตm |
6.45 ร 6.45 ยตm |
6.45 ร 6.45 ยตm |
UV Wavelength |
NA |
306 nm / 360 nm |
306 nm |
Illuminations |
Epi White |
Trans UV, Epi White, Epi UV |
UV, Epi White, Blue |
Emission Filter |
NA |
F590 |
F590 |
Software |
Geli, GelAn |
Geli, GelAn |
Geli, GelAn |
RGB Compatibility |
โ |
โ |
โ |
Applications |
|
|
|
Part Number |
Description |
GU-LE-M |
Motorized Zoom lens |
GU-TW-01-14 |
Foldable Trans white plate with uniform illumination |
GU-TUV-DW |
Dual UV wavelengths โ 306nm & 365nm |
GU-EF-460 |
Emission filter 460 nm (430โ490 nm range) |
GU-EF-535 |
Emission filter 535 nm (490โ560 nm range) |
GU-EF-620 |
Emission filter 620 nm (590โ650 nm range) |
GU-RGB |
RGB LED module for Fluorophore detection |
GU-1D-TL |
Additional 1D software |
GU-1D-LI |
Additional 1D software |
GU-TOUCH-10 |
10.1 Inch Touch Screen |
GU-TOUCH-15 |
15.6 Inch Touch Screen |
